Dyname 4.0 Drive System

DYNAME 4.0: TECHNICAL INFORMATION

Reduced size and weight

• The Dyname 4.0 motor is 18.5% lighter than the previous generation, Dyname 3.0.
• We’ve given our motor a weight reduction while also increasing reliability. The Dyname 4.0 motor features oversized bearings for increased drive durability.

A quiet drive system

• The Dyname 4.0 features a lower motor rpm that reduces the amount of the electrical whine compared to other systems.
• We’ve removed the upper chain slider that was seen on the Dyname 3.0 drive system to reduce the mechanical noise, as well as the drag when pedalling.

A responsive, natural power delivery

• Our system’s torque sensor reads the tension that is being applied directly to the chain, and removes unwanted lag time to give an instantaneous and natural response when the power is applied.
• We’ve developed a new torque curve that is designed to gradually apply power that achieves a maximum power of 700 W at optimal cadence (85rpm). By having a variable power curve, you’ll have more control of your bike on the trail including scenarios like steep, technical hill starts.

Torque and power

• The Dyname 4.0 drive system packs the same 108Nm of class-leading torque that the Dyname 3.0 brought to our previous generation of bikes.
• Our drive system has 700 W of peak output, meaning that more watts are delivered when you really need them.

BATTERY INFO

Battery size

• We’ve increased the capacity of the Powerplay battery from 672Wh to 720Wh, allowing you to spend more time riding.
• Our new Powerplay models feature an easily removable battery. Simply drop the protective cover and battery retention bolt, and it will slide right out of the frame.

Charging

• We have a 4-amp charger and a 2-amp charger for the all-new Powerplay models, both of which quickly refuel your battery to get you back out there, faster. The less powerful of the two, the 2-amp charger, will charge the battery from 0-100% in 7 hours and 35 minutes which outpaces the competition.

Overtimepack

• The all-new Powerplay is compatible with the new Overtimepack, which gives you an extra 314Wh of battery capacity on top of the 720Wh of battery capacity in the bike. That means you have a total of 1,034Wh of battery capacity to ride with before needing a charge.
